Variable speed fans for poultry - Michael Czarick

Published: April 18, 2018
Michael Czarick (University of Georgia) explained the advantages of using variable speed fans, including the reduction of power costs, during IPPE 2018 in Atlanta, USA.
Related topics:
Authors:
Mike Czarick
University of Georgia
University of Georgia
Influencers who recommended :
Kapil Manwal, Martin Rishoj
Recommend
Comment
Share
Tim M. Asbridge
Rose Acre Farms
Rose Acre Farms
4 de septiembre de 2019

Have one building using all variable speed fans. Cycling between 30% and 100% depending on summer and winter conditions. Ventilation at extremely low temps much more stable and comfortable by elimination of minimum cycling of fans at these temps. Fans are also controllable by automated environmental systems meaning that ventilation can be lowered even during evaporative cooling season increasing cooling efficiency. Another positive is that variable speed fans can be adjusted throughout the building to overcome problems or ventilation deficiencies. I have had no problems with ammonia increases in winter due to the fact that air is always moving and being replaced. There is some negative as far as shutters not fully opening at reduced speeds but not a major issue.

Recommend
Reply
Mike Czarick
University of Georgia
University of Georgia
30 de julio de 2018

Electricity costs can be reduced by installing energy efficient fans
or
using fans less...which will not help bird performance
or
keeping fans properly maintained
or
using variable speed technology

Recommend
Reply
Tim M. Asbridge
Rose Acre Farms
Rose Acre Farms
26 de julio de 2018

There are several ways, in my opinion, where variable drives can be very helpful. What I don't hear a lot of discussion about is multiple fans on individual drives, which can greatly reduce cost and the ability to correct deficiencies or stratification of air by using drive adjustments.

Recommend
Reply
Christopher Hettiarachchi
25 de junio de 2018

Application of this technology in broiler evap. cooling system can be a bonus to the industry. I am sure Dr. Michael Czarick must have considered all the important parameters such as concentrations of carbon dioxide, ammonia, oxygen and RH in addition to the temperature. If not, these parameters could also be integrated into the system.

Recommend
Reply
Dr. Ashraf Ali Qureshi
25 de junio de 2018
Very good explanation on variable fans. Variable speed fans are good to save energy when working on lower speed, but if not capable to achieve specific static pressure of the house to take inlet cool air in the center of the house and to mix it with hot air mixed with gases and to throw it out within 0.75 - 1 minute. Few fan types are not efficient to open their shutters completely when operated on low speeds.
Recommend
Reply
Syed Farjad Zaidi
4 de septiembre de 2019
Its 11.30 pm in Multan Pakistan temp is 34°C humidity 68%
Recommend
Reply
Syed Farjad Zaidi
4 de septiembre de 2019
When we discuss issue of forced ventilation in EC houses with different type of fans currently we talk about we assume cone fans with shutters instead of butter fly.Most discussed are broiler flocks.;what is the effect of all this on broiler breeders as in adult heavy birds wind chill effect is much different;in different geographical regions temp humidity ratio is higly variable. Currently we in Pakistan plains area facing a very different situation compared to near past high humidity with high temperature not as high as is use to be temp at 5 am is about 30C with ,75% humidity and at 5pm 39~40C with 60~65% humidity.trief pads of 10 and ,15 cm thickness with 45X45 Deg and ,,,45X15 deg fluting angle.Pads with 45X15°and 10 cm work better with timer on water supply but still the temp cross 32° inside house increasing air velocity donor work well plz advice some remedy
Recommend
Reply
Ing. Dragan Ionut
30 de julio de 2018

Thank you very much, Dr. Czarick for your articles. Can you explain a little bit about the importance of speed controller in this case? I know two kinds of speed controllers - one with voltage reduction and the other will reduce the frequency. I suppose the tension reduction is totally not useful. All the best.

Recommend
Reply
Md.akhtar-uz-zaman, Zaman
CVASU: Chittagong Veterinary and Animal Sciences University
30 de julio de 2018
Electric cost by speed can only be reduced by reducing electricity requirements in variable speed.
Recommend
Reply
Syed Farjad Zaidi
25 de julio de 2018

Do we need a different type of controller to operate variable speed fans?
Or can we go for a combination of fixed RPM and variable speed fan when the difference of day and night temperature is we.

Recommend
Reply
